Measuring range	0 - 1000 °C
Sensor	Thermopile
Spectral range	8 - 14 µm
Response time t90	≤ 100 ms
Measurement uncertainty	1 % of temp. reading [°C], min. 2 K
Repeatability	1 K
Temperature coefficient	0.1 K/K (T < 200 °C) 0.05 %/K (T > 200 °C)
Resolution interface	≤ 0.5 K

Lenses

Standard lens PZ focusing 0.3 m - ∞ Close-up lens PZ 10.05: focusing 0.15 m - 0.3 m

Analog output	0(4) - 20 mA linear, switchable, scalable
Resistance	≤ 500 Ω
Interface	Profibus DP
Power supply	22 - 27 VDC
Current consumption	≤ 80 mA

Sighting option	Through-the-lens-sighting
Sighting option	Laser pilot light

Connection	Screw terminals
Ambient temperature	0 - 60 °C
Storage temperature	-20 - +70 °C
Permissible humidity	95 % r.H. max. (non-condensing)
Dimension	Ø 65 mm x 180 mm
Housing	Aluminium
Protection class	IP 65 acc. to DIN 40050
Weight	approx. 0.5 kg

Parameters

Emissivity 10 to 99.9%; increment 0.1 % Smoothing filter Min./Max. peak picker Double maximum with adjustable hold time Device address Temperature unit °C/°F Diagnostic function

Overtemperature signal

if the internal temperature exceeds 65 °C the analogue output shows a value > 20.5 mA

Scope of delivery

Pyrometer CellaTemp PZ Manual GSD file on CD
